AR-32RM System - DMX Architectural real time recorder/playback system

Great for controlling LED or other room lighting in bars, clubs, restaurants or any commercial venue!

Comes with 32 built-in programs for RGB LED fixtures, therefore no initial programming is required to have a working system in no time!

System includes;

• AR-32RM  (rack mount)
• 1 AR-32 Remote
• 1 USB-cable
• 1 External AC Adaptor
• 1 User's Manual
• 1 AR-32 Configuration Software

OVERVIEW:

• The AR-32RM Architectural Recorder System is a lighting control system that records DMX signals from a separate
  controller and saves these recordings to scene (.scn) files for future playback.
• The AR-32RM includes computer software that is used to configure and load shows to the controller itself. The software is designed for use on Microsoft Windows computer operating systems.
• Multiple scenes may be loaded to each controller show location.  Shows may be played back manually using the AR-32 Controller, remotely using the IR remote or a DMX signal, or internally triggered using time and date.
• The AR-32RM comes pre-loaded with 32 shows designed for use with RGB type LED fixtures (strips, cubes, panels,
  etc.).  Shows 1-16 include static color scenes and Shows 17-32 include various rainbow chases.  All factory
  scenes are written for 512 DMX channels.   (set all fixtures to RGB or the programs will not work)

Features;

• 1 Space Rack Mount 512 Ch. Architectural Recorder/Playback System

• 512 DMX Channel recording
• Flash (.swf) file playback and conversion
• Up to 32 shows (4pages, 8 shows per page)
• Up to 16 scenes per show, with 248 scenes file capacity
• 128Mb memory capacity
• Real time individual triggering of desired scenes
• Playback via DMX Control Mode, Timed Trigger Mode, Manual Mode
• Record show hold and fade times
• DMX, Manual, Infrared and Auto trigger for show playback
• Link to PC (AR-32 Software) via USB input
• Synchronize clock for Auto playback
• Set Auto On/Off times

• Power failure memory

• 3 pin XLR DMX Input & Output
• Software available @ www.elationlighting.com
• Shipping Weight; 12 lbs
