OPTO BRANCH 4

4-Way DMX Distributor

One of the finest of its kind on the market today, and at an affordable price too!

OVERVIEW:

• This is a 19” single rack space, 4-way DMX distributor/booster with 3 and 5 pin XLR input jacks.
• This unit takes the incoming DMX signal and splits it to four separate outputs.
• All outputs include 3 & 5 pin XLR sockets and are electronically isolated from each other to ensure uninterrupted data. In addition, each output has dedicated drivers to boost the incoming signal.
• Finally, a Link Out/Terminate switch is in place to help make any troubleshooting easier.


FEATURES/SPECIFICATIONS:

• 4-way DMX distributor
• 19" rack mountable - single space
• 1 x DMX input, 4 x DMX outputs & 1 DMX thru
• All outputs are electronically & optically isolated
• 3 & 5 pin XLR DMX connectors
• Data + & Data - L.E.D. indicators
• Linkable with other OPTO BRANCH 4S via 3 or 5 pin XLR
• Link out/terminate button for troubleshooting
• 50mA internal fuse
• Power input: 120VAC ~ 60Hz
• Internal fuse: 05A 250V (5x20m)

• Dimensions: 19"L x 5.5"W x 1.73"H
• Weight: 5.29 lbs
