FOCUS SPOT 2X 100W LED Moving Head Light with 3W UV LED, 2 prism effects, rotating replaceable gobos
List Price: $1,259.95
Your Price: $899.99
Quantity:
Contact Us

New itemFree Shipping Available

Focus Spot 2X
Sku# FOC286

100W LED Moving Head Light with 3W UV LED, 2 Prism effects, rotating replaceable gobos & much more!

OVERVIEW:

The ADJ Focus Spot 2X is a 100W LED Moving Head with a 3W UV LED included for black lighting or additional color hues. It features two prism effects; a 6-facet circular prism and a 6-facet linear prism. In addition, ADJ has fitted the FS2X with a GOBO wheel with replaceable, rotating and indexable GOBOs. The GOBOs are easy to replace by removing the top housing with one screw that’s on a hinge. GOBOs easily lock in and out of the GOBO wheel. This mover is also equipped with motorized focus, Gobo Indexing, EZ Gobo replacement and a manual zoom knob near the lens to change the beam angle from 16 ~ 19 degrees.

The Focus Spot 2X is extremely versatile and has everything clubs, theaters, churches, concert productions and lighting professionals are looking for in a LED spot moving head. It has 16 & 18 DMX channel modes, Pan/Tilt Inversion, 16-Bit Fine Pan/Tilt, 3-pin DMX In/Out, locking In/Out power connectors, and a 4-Button DMX LCD menu.

The Focus Spot 2X is fitted with 8 colors plus spot and split colors. It has 6 rotating, replaceable GOBO patterns plus spot. The color wheel and GOBO wheel work independent of each other. All GOBOs are indexable.

Features:

• Motorized Focus
• Manual Zoom knob on head: 16 ~ 19 degree beam angle
• Fan cooled
• Strobe/Pulse effect; random strobe slow to fast
• UC IR & Airstream IR Compatible (Sold Separately)


Light Source:



• 1 x 100W Cold White LED (7600°K, 50,000 hr.)
• 1 x 3W UV LED



Color Wheel:

• 8 Colors + White & Split Colors


Gobo Wheel:


• 6 Rotating, replaceable Gobos + Spot
• Gobo Size: Outer: 23mm/Inner:19mm/Thickness: 0.5mm
• Gobo Indexing
• EZ Gobo replacement with hinged head cover
• Gobo Shake effect


Prism Wheel:



• 6-facet circular prism
• 6-facet linear prism



Control:


• 3 Operational Modes: Sound Active, Show Mode, & DMX Controlled
• Master / Slave-able
• 4 Built-in lighting shows
• 16 & 18 DMX channel modes
• Electronic Dimming: 0% - 100%
• 5 Dimmer Curves
• 4-Button DMX LED menu
• Stepper motors with micro stepping
• With Wired Digital Communication Network



Connections:

• 3-pin DMX In/Out
• Twist locking power In/Out connections on rear to daisy chain power (up to 9 Focus Spot 2X’s @ 120V and 16 Focus Spot 2X’s @ 230V)

Electrical:


• Multi-voltage Operation: 100-240V, 50Hz/60Hz
• Power Consumption: 175W


Pan/Tilt:


• Fast and precise Pan/Tilt Movements
• 16-Bit Fine Pan/Tilt control
• Pan: 540-degree
• Tilt: 270-degree
• Pan/Tilt Invert Mode
• 4, Built-In, Pan/Tilt Target Modes

What's Included:


• Includes Omega bracket for truss mounting
• Includes power cable

Dimensions / Weight:

• Dimensions (LxWxH): 9.33” x 9.10” x 15.15”/ 237 x 231 x 385mm
• Weight: 14.5 lbs. / 6.5 kgs.

Ships From: CA or FL stock
Average Delivery Time: 3-5 business days**
(** in stock product, from date of order, standard ground shipping, delivery within the lower 48 US states)






PRODUCT DETAIL
Sku: FocusSpotTwoX
Brand: American DJ
