Circa Scoop LED unique one-of-a-kind multi-effects fixture
List Price: $2,159.00
Your Price: $1,799.00
Quantity:
Contact Us
Free Shipping Available

view more images

Circa Scoop LED
Sku# 5200

CHECK OUT OUR 2-PAK FOR GREATER SAVINGS!

OVERVIEW:

  • Mega-lite presents the new and unique Circa Scoop LED, a next-level unit designed with four different elements that can be used in multiple applications. Built with a lightweight housing, the Circa features a variety of technological components that add a one of a kind look to any concert, church, theater or club.
  • Equipped with 45 WW and Amber LEDs located in the unit’s Center Engine it enables the unit to create a nice and warm sunset effect, ideal for theatrical utilization. The “Reflective Pattern Ring” has an additional 87 WW LEDs, which creates a nice soft-edged effect to any setting. The Circa also features an Inner Ring which has 144 RGB LEDs, 8 segment control and the capability to control the macro speed and dim down different colors enabling it to set a wide mixture of colors. The Outer Ring also features 8 segments and is equipped with an extra 192 RGB LEDs that illuminate a 140º angle. The 336 RGB LEDs can produce multiple color combinations and facilitate the ability to create authentic looks that can be used as dazzling eye-candy effects. In addition, the RGB LEDs also produce a bright cool white, allowing it to alter the mood and intensify or neutralize a color. The Inner and Outer Rings can generate pulsing random strobe and macro effects, giving the Circa Scoop further diversity within one single unit.
  • The Circa Scoop LED isn’t like any other fixture, with a modern twist it is an upscale unit designed to liven up any setting it is used in. Whether placed on the floor or rigged, this unique fixture can make any band or performer stand out from the rest. The Circa Scoop LED has the design and effects you’ve been looking for, let its multiple elements make you stand out from the crowd!

    NOTE: Removeable Floor Base shown in picture is not included, see Optional Accessories below

SPECIFICATIONS:

  • DMX CONNECTORS: 5-pin XLR Connectors
  • MOUNTING YOKE: Square Yoke included (Accessory Circular Yoke Available)
  • POWER CONNECTORS: Power Con Type
  • THERMAL:
    Maximum Ambient Temperature: 110º F
    Maximum Surface Temperature: 140º
  • FASTENING SYSTEM: One Quick Release Clamp Mount
  • LED QUANTITY: 336 RGB 87 Warm White 45 Warm White + Amber
  • FUSE: 5x20 F5AL250V
  • LED ANGLE: 140° (Outer Ring)
  • POWER INPUT VOLTAGE: 110V-240 50/60 Hz
  • BALLAST: Electronic Auto Switching
  • POWER CONSUMPTION: Watts: 428 Amps: 3.70
  • LED LIFETIME: *60 to 100 thousand hours
  • SCAN RATE: 7000Hz
  • SMD LEDS WATTS: 0.8 Watt Each
  • PROTOCOL: DMX 512 Protocol
  • DMX MODES:
    Mode 1: 2 Channels Dimmer, Macro
    Mode 2: 3 Channels Dimmer, Warm White, Amber
    Mode 3: 17 Channels Dimmer, Outer R, G, B, Macro, Macro Speed, Outer Strobe, Inner R, G, B, Macro, Macro Speed,
    Inner Strobe,Warm White, Amber, Reflective Center, Center Strobe
    Mode 4: 52 Channels Dimmer, Outer, RGB x 8, Inner RGB x 8, Warm White, Amber, Reflective Warm White
    Mode 5: 55 Channels Dimmer, Outer, RGB x 8,Outter Strobe, Inner RGB x 8, Inner Strobe, Warm White, Amber,
    Reflective Warm White, Center Strobe
  • Dimensions: (LxWxH) 10.8” x 20.68” x 19.25”
  • Weight: 18.3 lbs
  • Ships From TX Stock
  • Average Delivery Time: 3-5 business days**
    (** in stock product, from date of order, standard ground shipping, delivery within the lower 48 US states)

OPTIONAL ACCESSORIES:

  • Circular Yoke (part# 5200-HOU-RYoke)
  • Removeable Floor Base (part# 5200 ACC-Bas)

PRODUCT DETAIL
Sku: CircaScoopLED
Brand: Mega Lite
